Note: Product visuals are presented for illustrative purposes only and may vary slightly in colour, finish, proportions, and final installed appearance. For the most realistic representation, please refer to our Customer Gallery featuring actual installation photos.
Answer the door without opening it.
The bell rings. You're in the shower, on a work call, or your mum is home alone and has no idea who's outside. In most homes, the only way to find out is to open the door, squint through a tiny peephole, or dig for your phone and wait for an app to load.
The Mercury DB2 puts a 7 inch screen on your wall. In about a second, whoever is home sees exactly who's outside, talks to them, and decides whether to open up. No phone, no app, no guessing.
3pm. Mum is home alone.
A man at the gate says he's here to "check something". Mum doesn't recognise him. She sees him on the screen, taps to talk, and asks him to come back when her son is home.
At the same moment, your phone rings at the office. You see the same face and can speak to him yourself. Two people answering the door, and nobody opening it.
What this solves: the screen works for anyone at home, including elderly parents, kids back from school and helpers, with no phone and no app login.
The parcel that disappeared.
Parcel thefts from HDB corridors keep making the news, sometimes minutes after the delivery rider leaves. When someone walks up to your door, the DB2's motion sensor picks them up and records a clip automatically, before they've even touched the bell.
Here's what most doorbells get wrong: they keep the recordings in the outdoor unit. The DB2 saves them on the 32GB microSD card inside the indoor display, in your home. Even if someone pulls the doorbell off the door, the evidence stays with you.
No cloud plan, no monthly fee. Replay every clip from the screen or your phone.
When the Wi-Fi drops, the doorbell doesn't.
The outdoor unit and the indoor display talk directly to each other. If your internet goes down, the display still rings, still shows your visitor and still records. Only checking from your phone pauses until you're back online.
When your Wi-Fi is up, the DB2 connects on 2.4GHz or 5GHz. Most doorbells only use the crowded 2.4GHz band. 5GHz gives the video a clearer lane, so live view stays smooth. Your visitor appears on the screen in about 1 second, and on your phone in about 3 to 5 seconds.
Built for real life at a Singapore door.
Night, rain and corridor glare
Infrared night vision, a 160° wide angle lens, an IP55 rated housing and a built-in hood that shields the lens from rain and overhead light. Faces stay clear at 3pm and at 3am.
A bell you can actually hear
Choose from several ringtones and set the volume on the display. Motion sensitivity goes Off, Low or High, so you decide how much corridor activity you want to be told about.
Charge every few months, not every week
The 7000mAh outdoor battery lasts up to 6 months per charge, depending on how busy your door is. When it's time, slide off the cover, pop the battery out and charge it over USB Type C. The doorbell stays on the door. The indoor display can stay plugged in all the time.
No drilling into your new door
We mount the DB2 with strong 3M adhesive, so your new BTO door, condo door or gate stays untouched. Installation by our team is included.
HDB-friendly placement
The DB2 is a smart doorbell on your own door or gate. We angle it at your doorstep, not at your neighbour's door or windows, so it stays a doorbell for you and not a camera on them.
An app that will still be here in five years
The DB2 runs on Tuya Smart, one of the world's largest smart home platforms, so the app keeps getting support and updates instead of vanishing if a small brand closes shop. Your video stays on the microSD card at home. Share access with the family as Admin or Member.
Why the DB2, not a $99 doorbell?
| Mercury DB2 | Typical phone-only doorbell | |
|---|---|---|
| Who can answer | Anyone at home, on the 7" screen | Only people with the app |
| See your visitor | About 1 second on screen | Find your phone, wait for the app |
| If the doorbell is taken | Footage safe inside your home | Card often goes with it |
| Internet down | Still rings and records | No alerts |
| Wi-Fi | 2.4GHz or 5GHz | Usually 2.4GHz only |
| Monthly fee | None, 32GB card included | Often a cloud plan |
| Installation | Included, by Interlock, no drilling | Do it yourself |
Your phone isn't always in your hand. The screen is always on the wall.
See who's there. Then decide.
Installation included, 1 year local warranty, fitted by our team since 2008. Have a gate too? Our Mercury G3 and G4 gate locks have a camera and intercom built in. Send us a photo on WhatsApp and we'll suggest the best setup.
| Model | Interlock Mercury DB2 (display model TL-WF701) |
|---|---|
| Product Type | Smart wireless video door phone (outdoor camera + 7 inch touchscreen display) |
| Camera Resolution | 1080p HD, 160° wide angle lens |
| Indoor Display | 7 inch touchscreen, 1024 x 600 resolution |
| Connectivity | Built-in Wi-Fi, 2.4GHz or 5GHz (5GHz recommended first), Tuya Smart App (iOS and Android) |
| Camera Battery | 7000mAh, DC5V charging, standby draw 500uA / working draw 240mA, USB Type C. Battery is removable from the camera cover for charging separately |
| Display Battery | 5000mAh, DC5V charging, USB Type C, working current 500mA |
| Camera Dimensions | 14.4 x 5.1 x 3.5 cm |
| Display Dimensions | 18.1 x 13.3 x 2.2 cm |
| Operating Temperature | -20°C to 60°C (camera and display) |
| Water Resistance | IP55 (outdoor camera) |
| Camera Hood | Built-in hood shields the lens from rain and overhead glare |
| Night Vision | 850nm infrared night vision (outdoor camera) |
| Local Storage | 32GB microSD card (unbranded) included free, local storage only, no cloud subscription required (slot supports up to 128GB) |
| Motion Detection | PIR sensor with Off, Low or High sensitivity, adjustable monitor time and trigger interval. Automatically records a video snippet on every trigger |
| Intercom | Full duplex two way talk |
| Unlock Button | Not used. The DB2 is a doorbell only and doesn't unlock doors or gates |
| Multi User Access | Home sharing via Tuya Smart App with Admin and Member permission levels |
| Pairing | QR code scan or automatic discovery via the touchscreen, camera pre-paired to display from factory |
| Mounting | 3M adhesive, no drilling or wiring required |
| Warranty | 1 year local warranty on all parts, excluding the included microSD card |
| In the Box | 7 inch touchscreen display, outdoor camera, power adapter, USB Type C charging cable, 32GB microSD card (unbranded), installation accessory kit, user manual |
| Certification | CE, FCC, UKCA |
Frequently Asked Questions
Have questions? We're here to help you.
Three reasons. First, the 7 inch indoor screen shows your visitor in about 1 second, so anyone at home can answer, even without a phone. Phone-only doorbells depend on your phone being nearby, charged and not on silent. Second, your recordings are saved on the microSD card inside the indoor display, so they stay safe in your home even if the outdoor unit is tampered with. Third, it connects to 2.4GHz or 5GHz Wi-Fi for a steadier connection, and it is installed and supported locally by Interlock.
Yes. When someone presses the bell, the 7 inch touchscreen lights up with the visitor's face. Tap to talk, no app or login needed. It's a simple way for elderly parents or a helper to check who is outside before opening the door.
The indoor screen shows your visitor in about 1 second. Phone notifications through the Tuya Smart app arrive in about 3 to 5 seconds, depending on your internet connection. You can also tune the motion sensor to Off, Low or High so it wakes up the way you want.
The outdoor unit's 7000mAh battery lasts up to 6 months per charge, depending on how often it's triggered and your motion sensitivity setting. When it's time to charge, pop the battery out and charge it over USB Type C. No need to take the doorbell down. The indoor display can stay plugged in all the time.
Your footage is safe. Recordings are saved on the microSD card inside the indoor display, not in the outdoor unit, so the evidence stays inside your home.
Yes. The outdoor unit and indoor display are paired directly, so the display still rings, shows your visitor and records locally. Only checking from your phone pauses until the internet is back.
No. A 32GB microSD card is included, and every motion and call recording is stored locally. No cloud plan, no monthly fee, ever.
Save any clips you want to keep, then format the card from the display to start fresh. The slot supports cards up to 128GB if you'd like more space.
The DB2 is a smart doorbell mounted on your own door or gate, which HDB allows for communicating with visitors and delivery riders. We angle it toward your own doorstep, not your neighbour's door or windows. If you want anything mounted on common property, such as the corridor wall, your Town Council's approval is needed separately.
No. We mount it with strong 3M adhesive, so there's no drilling into your new BTO door, condo door or gate. Installation by our team is included in the price.
The indoor display has several ringtones and adjustable volume, so you can set it loud enough to hear around the home, or softer at night.
Tuya is one of the world's largest smart home platforms, so the app keeps working and getting updates long term, not tied to a small brand that may close shop. Your video recordings are stored locally on the microSD card in your home, not on a cloud server.
Yes. Share access through the Tuya Smart app with Admin or Member permissions, so everyone can check the door without everyone controlling the settings.
Yes. It has 850nm infrared night vision, an IP55 rated housing and a built-in hood that shields the lens from rain and overhead glare.
No. The DB2 is a doorbell only and doesn't unlock doors or gates. The button is part of the standard display layout and has no function on this model.
Maybe not. Our Mercury G3 and G4 gate locks have a camera and intercom built in. The DB2 suits homes without a gate, or where you're keeping your current gate lock. Send us your door and gate photos on WhatsApp and we'll recommend the right fit.
