Note: Product visuals are presented for illustrative purposes only and may vary slightly in colour, finish, proportions, and final installed appearance. For the most realistic representation, please refer to our Customer Gallery featuring actual installation photos.
为什么重要
为您真实的回家方式而设计。
使用 Assa Abloy (iRevo) Gateman SP121 升级您的家居安全。作为全球领先的门禁解决方案供应商，Assa Abloy (iRevo) 是韩国排名第一的电子锁制造商，其推出的这款产品 SP121 提供便捷的密码和刷卡访问方式，价格实惠。凭借其时尚的设计和坚固耐用的结构，这款门锁既美观又实用，是您家居的理想之选。
Real installation photos from our customers.
| Model | Gateman GR-Sash |
|---|---|
| Lock Type | Rim - compact vertical design for narrow door frames |
| Unlocking Methods | PIN Code (1 shared password, 4-12 digits), RFID Card |
| Connectivity | None - fully offline, no app/Bluetooth/Wi-Fi |
| Power Source | 4x 1.5V AA (LR6) alkaline batteries; DC 6V rated; 9V external emergency power terminal |
| Battery Life | Up to 1 year (based on ~10 uses/day) |
| Warranty | 1 Year Parts and On-Site Warranty |
| Dimensions | Front (exterior) body: 68mm (W) x 165mm (H) x 23mm (D); Main (interior) body: 75mm (W) x 179mm (H) x 39mm (D) |
| Material | Front body: ABS + Aluminum; Main body: ABS + Aluminum |
| Card Key Capacity | Up to 100 registered card keys |
| What is in the Box | Front Body, Main Body, Strike, Stopper, Indoor Fixing Plate, Manual, Guarantee Card, Construction Paper, Batteries x4, Card Key x2, Screw |
| Suitable Door Types | Wooden Door |
| Security Features | Smart etiquette silent unlock, anti-peep fake-number entry, internal/external forced-lock mode, auto-lock (within 1 second of closing) or manual lock, intrusion and high-temperature alarms, 5-minute lockout after 5 failed attempts |
